Description
| BenQ Interactive Flat Panel Technical Specifications | |
| Panel | Screen Size: 86 Inch Panel Type: IPS Resolution: UHD 3840 × 2160 pixels Active Area: 1895.0 x 1096.0 mm Response Time: 8 ms Aspect Ratio: 16:9 Orientation: Landscape Contrast Ratio: 1200:1 Dynamic contrast ratio: 30,000:1 Color depth: 10-bit Color gamut: 68% NTSC Panel brightness without glass (typical): 450 nits Panel brightness with glass (typical): 400 nits Backlight Life (Typical): 50,000 hrs |
| Glass | Hardness: 9H tempered Anti-Glare: Yes Germ-resistant Technology: Yes |
| Touch Screen | Touch Technology: Precision IR Touch Points: Up to 40 Touch Response Time: < 5 ms |
| System | CPU: Arm Cortex-A73 × 4 + A53 × 4 GPU: Arm Mali-G52 MP8 Memory| Built in Storage: 8 GB | 64 GB Storage (SD Card Slot): 512 GB Operating System: Android 13 (EDLA) |
| Connectivity | HDMI x 4, VGA x 1, PC Audio In x 2, Audio out x 1, LAN x 1, RS232 x 1, OPS Slot for PC x 1 USB-C: 1 × 3.0 (PD 65 W), 1 × 2.0 USB Type-B (for touch): 2 × 2.0 USB Type-A: 2 × 2.0 + 2 × 3.0 |
| Built in Peripherals | Speaker: 2 x 20W Sound Output Ambient Light Sensor, IR Sensor |
| Power | Energy Star: Yes Power: Voltage: 100V-240V, 50/60Hz Standby Power Consumption: <0.5 W Typical Power Consumption: 85 W |
| Physical | Dimensions (W x H x D): 1962.4 × 1174.9 × 87.1 mm Shipping dimensions (W x H x D): 2095.0 × 1265.0 × 185.0 mm Weight (product I shipping): 65.2 kg | 82.9 kg Mount (screws): VESA 800 × 600 mm |
| Environment | Operating Temperature: 0°C ~ 40°C (32°F ~ 104°F) Storage Temperature: -10°C ~ 60°C (14°F ~ 140°F) Operating Humidity: 20% ~ 80% RH (non-condensing) Storage Humidity: 10% ~ 80% RH (non-condensing) |
| Software | Whiteboarding: EZWrite 6.0 Wireless screen sharing: InstaShare 2 Device management: DMS Account management: AMS Quick access tool: Floating Tool Broadcast system: X-Sign Broadcast |
| Accessories | Cables: 1 × VGA (3 m), 1 × HDMI (3 m), 1 × USB-B for touch (3 m), 1 × USB-C (1.5 m) Wall mount x 1, Pen x 2, Remote Control x 1. |
| Warranty | 3 Years |
